Silent 6CTA 8.3- G2 Turbocharged Diesel Engine For 50Hz / 60Hz 200KVA Generator

Name: Silent 6CTA 83 G2 Turbocharged Diesel Engine For 50Hz 60Hz 200KVA Generator
Brand: Cummins
Price: 1 USD

Wholesale Silent 6CTA 8.3- G2 Turbocharged Diesel Engine For 50Hz / 60Hz 200KVA Generator from china suppliers

Brand Name : Cummins

Model Number : 6CTA 8.3-G2

Certification : ISO14001:2004

Place of Origin : Xiangyang City in Hubei China

MOQ : 1 unit

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 200 units/per month

Delivery Time : 3-7 working days on receipt of yr advance payment

Packaging Details : wooden case, neutral packaging or packaged as our customers' request

Fuel : Diesel

Engine Model : 6CTA 8.3-G2

Bore&Stroke : 114mm*135 mm

Cylinders : 6 in line

Aspiration : Turbocharged & Intercooled

Rated Power : 170 kw

Speed : 1800rpm

Displacement : 8.3L

Contact Now

Silent 6CTA 8.3- G2 Turbocharged Diesel Engine For 50Hz / 60Hz 200KVA Generator

Data Sheet of 6CTA8.3-G2:

General Technical Specification of Cummins 6CTA8.3-G2 diesel engine
Engine type	Vertical In-line, 4 stroke.
Cylinder number	6 cylinders
Displacement	8.3 L
*BoreStroke**	114*135 mm
Aspiration	Turbocharged & Intercooled
Combustion type	High-pressure common rail, direct injection
Rated power	170 kw
Rated Speed	1800 r/min
Dry weight	650 kg
Overall Dimension	1115716751 mm

Engine Features:
1. Powered By DCEC ENGINE
2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection
3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler
4. Machinery or electronic governing
5. Fuel injection pump
6. Electric motor starting system
7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
8. Low discharge, and low fuel consumption
9. Installed conveniently and maintain easily

Generator set List:

Item	Model	Power/Speed(kw/rpm)	Remark
1	4BT3.9-C80	60/2000	Industrial Use
2	4BT3.9-C100	75/2400
3	4BT3.9-C105	77/2800
4	4BTA3.9-C125	93/2200
5	4BTA3.9-C130	97/2500
6	4BTAA3.9-C115	95/2500
7	4BTAA3.9-C125	93/2200
8	6BT5.9-C150	112/2400
9	6BTA5.9-C150	112/1800
10	6BTA5.9-C170	125/2300
11	6BTA5.9-C180	132/2200
12	6BTAA5.9-C180	132/2200
13	6CTA8.3-C215	160/2200
14	6CTAA8.3-C215	160/2200
15	6CTA8.3-C240	179/2200
16	6CTA8.3-C260	194/2200
17	6LTAA8.9-C325	239/2200

Other Engines we supply:
Silent 6CTA 8.3- G2 Turbocharged Diesel Engine For 50Hz / 60Hz 200KVA Generator

Packaging & Delivery
Packaging Details
Engine Assembly standard wooden case, neutral packaging or packaged as our customers' requirements
Delivery Detail
Shipped in 10-15 days after recipt of yr advance
