DCEC Cummins 75KW / 100HP turbocharged 4 cylinder engine 4BT3.9-C100 For Engineering Machinery
Cummins B Series Engine Advantages:
1. High fuel efficiency.
2. The durability and compact dimensions.
3. The design of dual ni-resist pistons and greater main bearing area:.
4. Advanced design and manufacturing.
5. Excellent cold start performance.
6. Excellent performance and advantage.
Specification:
| Engine model | 4BT3.9-C100 |
| Engine series | Dongfeng 4BT Series |
| Engine manufacturer | Dongfeng Cummins Engine Co., Ltd |
| Suitable for | Construction Machine |
| Air intake ways | Turbo charged, mid-cooling |
| Cylinder number | 4 |
| Fuel type | Diesel |
| Engine cylinders position | 4 cylinders in line |
| Displacement | 3.9L |
| Emission level | Euro 1 |
| Max output power | 75kw |
| Rated power speed | 2400RPM |
| Max horse power | 100HP |
| Max torque | 330N.m |
| Max torque speed | 1500r/min |
Features:
1) Engine:
a) Under the license of Cummins Engine Company of the United States
b) Wuxi Weifu fuel system and the technology of turbocharger and aftercooler,higher power output
c) Lower fuel and lubrication oil consumption
2) Alternator:
a) Optional permanent magnet generator (PMG) system provides constant excitation under all conditions
b) Easy paralleling with mains or other generators, standard 2/3 pitch winding avoids excessive neutral currents
c) Dynamically balanced rotors with sealed-for life ball bearings and single construction
d) Class "H" insulation system
e) Wide range of flange adapters and disc couplings
f) Conforms to all leading industrial and marine standards
Cummins Industrial Diesel Engine Model List:
| Cummins Diesel Engine Model List |
| Model | Rated power/Speed | PeakTorque/Speed |
| (kW/rpm) | (N.m/rpm) |
| 4BT3.9-C80 | 60/2200 | 330/1500 |
| 4BT3.9-C100 | 74/2400 | 330/1500 |
| 4BT3.9-C105 | 77/2800 | 330/1500 |
| 4BTA3.9-C80 | 82/2200 | 360/1400 |
| 4BTA3.9-C100 | 74/2200 | 410/1500 |
| 4BTA3.9-C110 | 82/2200 | 460/1500 |
| 4BTA3.9-C125 | 93/2200 | 475/1500 |
| 4BTA3.9-C130 | 97/2500 | 475/1500 |
| 6BT5.9-C130 | 97/2200 | 560/1500 |
| 6BT5.9-C150 | 112/2400 | 580/1500 |
| 6BTA5.9-C150 | 112/2200 | 670/1300 |
| 6BTA5.9-C170 | 125/2300 | 630/1400 |
| 6BTA5.9-C180 | 132/2200 | 750/1300 |
| 6CTA8.3-C195 | 145/1900 | 820/1500 |
| 6CTA8.3-C215 | 160/2200 | 908/1500 |
| 6CTA8.3-C230 | 172/2200 | 1003/1500 |
| 6CTA8.3-C240 | 179/2200 | 1028/1500 |
| 6CTA8.3-C260 | 194/2200 | 1135/1500 |
| 6LTAA8.9-C295 | 220/2100 | 1350/1400 |
| 6LTAA8.9-C300 | 225/2200 | 1268/1000 |
| 6LTAA8.9-C325 | 239/2200 | 1250/1500 |
| 6LTAA8.9-C340 | 250/2200 | 1380/1500 |
| 6LTAA8.9-C360 | 264/2200 | 1480/1500 |
Our Services:
1) we focus in diesel engine and engine parts for over 9 years
2) strong in resources integration
3) with freedom deep service
4) cheapest shipping
Packaging & Delivery
Packaging Detail:
Packaged By Exporting plywood case,woooden.
Delivery Detail:
Shipped in 3-10 working days after yr advance payment
FAQ
1. Q: What’s the MOQ for this model?
A: The MOQ for this products is 1 unit.
2. Q: Do you have this model in stock?
A: Usually, we have the industrial diesel engines, truck diesel engines and G-drive diesel engines of Cummins B/C/L series in stock. If customers want to place the order of marine engines, it will need about 25 working days of delivery. If your order quantity is more than 5 units, please contact our sales people to get the delivery time.
3. Q: How about the production capacity?
A: FYI, the current production capacity for our Dongfeng Cummins diesel engines is 500 units/day. For Chongqing Cummins diesel engines is 50 units/day.
4. Q: Can I mix several models in a container?
A: Yes, this is acceptable. Please ask our sales to calculate the quantity for you.
We can provide ORIGINAL CUMMINS engines used for Industry, Bus, Marine, Generator Set and water pump. More details, please contact us via email and call. Thanks !
